KS188-2

KS188-2 Built-in rod-changing integrated drilling rig

TEL : +8618029255858

Product Features Product parameters

Mainly used for drilling operations in small and medium-sized mines, such as open-pit coal mines, metak mines, ceme NT mines, ETC; for main Blasting holes.

Hole diameter：90-160mm

Drilling dept：22m

Engin: Yuchai National III 228KW

Compressor: 18m³/min 20bar

Weight: 11.5T

Feed travel: 4300mm

Rotate torque:3800N.m

Feed length: 6000mm

Feed compensate: 900mm

Max pulling force: 35KN

Fuel volume: 400L

Climbing capacity:30°

Drilling Hardness: F=6-20

76 Automatic Rod Change Library: 6+1

LXWXH: 8800X2300X2600mm
